Belt Conveyor Manufacturer in India
Belt Conveyor Manufacturer in India
Neo Conveyors designs and manufactures horizontal, inclined, telescopic, assembly-line, troughed, inspection and loading belt conveyors at its Ghaziabad, Uttar Pradesh plant, specified to your throughput, belt type and floor layout, with installation across India.
- PVC / PU / rubber belt, 300–1500 mm
- Up to 200 TPH
- MS / SS304 / SS316 construction
FIG. 01 — GENERAL ARRANGEMENT, BELT CONVEYOR
Industrial Belt Conveyor Systems
A belt conveyor uses a continuous belt loop, driven by a geared motor or drum motor, to move product along a controlled path. Belt type, pulley design, frame material, side guards, speed control and bed construction are all selected against product weight, hygiene requirement, incline angle and operating environment.
Choose the Right Belt Conveyor
The right conveyor is chosen around the product, not just the length. Neo Conveyors specifies belt, bed type, motor power, side guards and frame material together, so the installed system runs smoothly in daily production.
- PVC belts for general cartons, bags and unit-load movement.
- PU belts and stainless-steel frames for food and pharma lines.
- Rubber or troughed belts for abrasive bulk materials.
- Cleated belts when product moves upward on an incline.
Seven Belt Conveyor Types
Choose a standard conveyor type, or combine several into one line covering receiving, production, inspection, packaging and dispatch.
Horizontal Belt Conveyor
Flat motor-driven belt for cartons, bags, components and packed goods in production lines and warehouses.
View specification →Inclined Belt Conveyor
Cleated or rough-top belt conveyors for moving product between floors, mezzanines and packing levels.
View specification →Telescopic Belt Conveyor
Extendable conveyor that reaches inside trucks and containers to cut manual loading labour.
View specification →Assembly Line Conveyor
Speed-controlled workline conveyors for paced production, inspection and operator stations.
View specification →Troughed Belt Conveyor
Three-roll troughing idlers contain grain, cement, fertiliser, coal, sand and other bulk material.
View specification →Inspection Conveyor
Low-speed conveyor with clean frames, optional lighting and comfortable inspection zones.
View specification →Loading & Unloading Conveyor
Heavy-duty dock conveyors for moving goods between vehicles and the plant or warehouse floor.
View specification →Technical Specifications
Share product dimensions, weight, line speed, floor length and height difference; Neo engineers calculate belt type, drive power, frame design and layout from there.
Belt Width
Available from 300 mm to 1,500 mm, sized to product footprint and required capacity, up to 200 TPH on bulk material duty.
Conveyor Length
Built to custom length per plant layout, with inclines from 0–35°; cleated or rough-top belts are used on the steeper angles.
Belt Material
PVC for general cartons and bags, PU food-grade for hygienic lines, rubber or troughed for bulk material, cleated or sidewall for incline transfer.
Drive System
Geared motor or drum motor drive, fixed speed or VFD-controlled, running on a 415 V, 3 phase, 50 Hz supply.
Frame Material
Mild steel for general duty, SS304 or SS316 for food and pharma environments, with slider or roller bed depending on load.
| Belt width | 300 mm to 1,500 mm |
|---|---|
| Conveyor length | Custom, per plant layout |
| Capacity | Up to 200 TPH, bulk material |
| Belt type | PVC, PU food grade, rubber, cleated or sidewall |
| Inclination | 0–35°; cleats for steep angles |
| Drive type | Geared motor or drum motor |
| Structure | Mild steel, SS304 or SS316 |
| Power supply | 415 V, 3 phase, 50 Hz |
Applications
Belt selection changes by product: PU for hygienic food and pharma, rubber for abrasive bulk goods, PVC for general cartons and bags, cleats for incline transfer.
Warehousing
Carton movement, sorting lanes, dock feeding and dispatch conveyors.
E-Commerce
Parcel and shipment movement for picking, packing and truck loading.
FMCG
Packaging conveyors between filling, labelling, cartoning and end-of-line sections.
Food Processing
Food-grade PU belt and stainless-steel structures for clean production zones.
Pharma
Clean conveyor frames for blister packs, bottles, cartons and inspection lines.
Cement & Minerals
Troughed rubber belt conveyors for bulk, abrasive, high-capacity material flow.
Belt Conveyor vs Roller Conveyor vs Chain Conveyor
Belt Conveyor
Best for bags, cartons, loose items, incline transfer, food-grade surfaces and bulk material when troughed.
Roller Conveyor
Best for rigid cartons, totes and pallets with flat bases. Gravity roller options can run without power.
Chain Conveyor
Best for heavy pallets, automotive fixtures, metal parts and high-load industrial transfer.
FAQs
What is a belt conveyor?
A belt conveyor uses a continuous belt stretched between a drive pulley and a tail pulley to carry product from one point to another.
What is the price of a belt conveyor in India?
Price depends on belt width, length, capacity, belt type and frame material — mild steel, SS304 or SS316. Share your product and layout details for a custom quote.
Can belt conveyors work on an incline?
Yes. Neo Conveyors builds inclined belt conveyors for 0–35 degree inclines, using cleated or rough-top belts for steeper angles.
What belt types are available?
PVC for general cartons and bags, PU food-grade for food and pharma lines, rubber or troughed for abrasive bulk material, and cleated for incline transfer.
Do you install across India?
Yes, PAN India — including Delhi NCR, Ghaziabad, Noida, Gurugram, Faridabad, Ahmedabad, Pune, Hyderabad, Chennai, Mumbai, Bangalore, and UAE & Africa.
Belt Conveyor Manufacturer Across India
- Delhi NCR
- Ghaziabad
- Noida
- Gurugram
- Faridabad
- Ahmedabad
- Pune
- Hyderabad
- Chennai
- Mumbai
- Bangalore
- UAE & Africa
Request a Free Layout & Quotation
Neo Conveyors will recommend the correct belt conveyor type, belt material, motor power, width, speed and installation layout.
